| MEDIDA | CÓDIGO | Ø INTERNO (mm) | Ø EXTERNO (mm) | ESPESOR PARED | MTS |
|---|---|---|---|---|---|
| 1/8 " | MNG 3/6 | 3 | 6 | 1,5 | 50 | 3/16" | MNG 4/6 | 4 | 6 | 1 | 50 |
| 3/16" | MNG 4/7 | 4 | 7 | 1,5 | 50 |
| 3/16" | MNG 5/7 | 5 | 7 | 1 | 50 |
| 3/16" | MNG 5/8 | 5 | 8 | 1,5 | 50 |
| 1/4" | MNG 6/9 | 6 | 9 | 1,5 | 50 |
| 5/16" | MNG 7/10 | 7 | 10 | 1,5 | 50 |
| 5/16" | MNG 8/11 | 8 | 11 | 1,5 | 50 |
| 3/8" | MNG 9/12 | 9 | 12 | 1,5 | 50 |
| 3/8" | MNG 10/14 | 10 | 14 | 2 | 25 |
| 1/2" | MNG 12/15 | 12 | 15 | 1,5 | 25 |
| 5/8" | MNG 14/18 | 14 | 18 | 2 | 25 |
| 5/8" | MNG 15/19 | 15 | 19 | 2 | 25 |
| 3/4" | MNG 19/23 | 19 | 23 | 2 | 25 |
| 1" | MNG 25/28 | 25 | 28 | 1,5 | 25 |
Se fabrican medidas especiales a pedido.
